Elegoo Resin Funnel Cap
3D
Published 2022-06-24T07:56:11+00:00
494
16
Add to Collection
Printing Details
Just rotate it like on my photo and it will print without supports (My CR-10 v2 with 0.6 nozzle printed it pretty ok)
Layer Height: 0.2mm
Wall Thickness: 1.2mm
Wall Line Count: 2
Bottom/Top Layers: 6
Infill: 20% Lightning
I Printed it with REC PLA and it feels strong
Nozzle Temp: 205 C
Build Plate Temp: 55 C
Print Speed: 50mm/s
Retraction Distance: 5 mm
Retraction Speed: 45 mm/s
Brim with 6 line Count
But you know, you probably can print it much faster with less quality (We don't need visuals anyway, tho it will be easier to clean it if everything is smooth)
Technical Information
| Date published | 24/06/2022 |
| Time to do | - 480 minutes |
| Material Quantity | 98g |
| Dimensions | 122x122x105 |
| Support Free | YES |
More Information
Object Parts
Awesome! Thank you! This is perfect
