The Heist - Puzzle Box is an original design by Leisure Luke. It's a 23 Piece Puzzle Box that is SUPER EASY TO PRINT! No Supports Needed. Print it in PLA! Parts without squiggly springs can be PETG or PLA. Very little plastic used!
0.1mm tolerance for all non-sliding parts.
0.2mm tolerance for sliding parts
Verified to Print well at 100% and 150% sizes (0.4mm nozzle, 0.2mm layer height)
My Colors for each .stl model
Gold: Gold, Tool
White: Bolt, Barrel, BarrelSpring, BarrelPinV2
Marble: HeistLid, UpperBoltClamp, LowerBoltClamp, SafeBar, Spacer, Heist_Base_SafeCo_Pv5, Dial
Black: VaultDoor, Clips_Print_3_of_These, ClipSpring
Red: Pins_2_and_3, Pin_1, PinClip, DoorButton
You should be able to straight from the PRINT bed to ASSEMBLY! No External parts needed - no metal springs, no bearings, no magnets, no electronics, NO GLUE, NO SANDING... you get the idea!
As tested - 100% PLA 3D Printed!
Print all 20 pieces and 3 clips and they'll fit together pretty easily. Watch the YouTube video, I use a pliers for some parts of the assembly, especially at 100% size.
Again, see the YouTube Videos to get excited, for assembly, and if needed, to show the solve as well!
Comment, Provide Feedback, I always want to improve these puzzles for the final larger project!
These are all modular pieces that will be a part of a larger project... that I rambled on about in Episode 1 :P Basically, each puzzle becomes a side of Puzzle box that I call - the 5 aces. After the 4th Puzzle Box I'll release the final pieces required to do the full "5 Aces" Assembly. I'll also be printing and sending that puzzle box to a few youtubers to solve, and possibly selling a fully-assembled version on Etsy (if people are interested). Thanks for all the likes and feedback! I need more feedback always!
I'd love a like, follow, subscribe, etc. I'm hoping I can keep making cutting edge puzzle boxes bigger better and FREE for a long time!!!!
Check Out The Key &The Launch Puzzle Boxes at my Thingiverse Page!
Like, Subscribe, Follow, Collect, and I'll keep making puzzle boxes!
5/6/2021 10:29PM UPDATE - BarrelPinV2 now posted, resolving 1st layer height issue.
5/7/2021 3:35PM UPDATE - PinClipV2 resolves issue getting "stuck" when barrel is at 45 degrees.
Artillery Sidewinder X1 V4
Black, Red Silk, Marble, White, Gold
All Parts can be printed in PLA or PETG
